Universal 3 or 4 Link Lower Axle Side Bracket (10°) – DXF Files
Building your custom suspension setup? These DXF files allow you to cut and fabricate your own universal lower axle-side link brackets, designed for triangulated 3-link and 4-link suspension configurations.
🔹 CNC-ready DXF files optimized for plasma, laser, or waterjet cutting from 1/4" steel 🔹 Designed for 3.5" axle tube 🔹 10° angled bracket design for improved joint alignment in triangulated setups 🔹 Flat-cut tab and slot design — no bending required 🔹 Designed to fit 2.625" (2 5/8") wide suspension joints (Johnny Joints, flex joints, or rod ends with high-misalignment spacers) 🔹 Includes 9/16" mounting holes, can be edited or drilled to 5/8" or larger as needed
These digital DXF files are in standard inch, and intended for personal or commercial fabrication use. No physical brackets, hardware, or materials are included.
